3TK2825-1BB40
Siemens 3TK2825-1BB40 available at EU Automation. Get in touch today for a quick price.
Based on over 4900 reviews
Full 12-month warranty
Available for dispatch immediately
We deliver worldwide
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
All orders are subject to product availability. See our T&Cs.
Ask our team
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
The Siemens 3TK2825-1BB40 is a SIRIUS Safety Relay designed for reliable monitoring and control of safety functions in industrial applications. This versatile device is suitable for monitoring safety sensors, emergency stop circuits, and safety door switches. With a compact design, it features screw and snap mounting options, making it easy to integrate into your automation system. The 3TK2825-1BB40 operates with a 24V DC control supply voltage and offers a SIL3 safety integrity level according to IEC 61508, as well as a Performance Level (PL) e according to EN ISO 13849-1. This safety relay is equipped with 2 conventional signaling contacts and 3 safety-oriented contacts for secure and efficient operation. Approved by BG, SUVA, UL, CSA, EN 60204-1, EN ISO 12100, EN 954-1, and IEC 61508, the Siemens 3TK2825-1BB40 is a reliable choice for your safety control needs.
| Specification | Description |
|---|---|
| Part Number | 3TK2825-1BB40 |
| Alternative Part Number | 3TK28251BB40 |
| Manufacturer | Siemens |
| Category | Soft Starts |
| Voltage Type | DC |
| Control Supply Voltage | 24V DC |
| Coil Operating Range | 0.85 - 1.1 |
| Mounting Position | Any |
| Mounting Type | Screw and Snap Mounting |
| Width | 44.8 mm |
| Height | 138.5 mm |
| Depth | 120 mm |
| Electrical Connection | Screw Connection |
| Connectable Conductor Cross-Section | 1x (0.5 - 4.0 mm²), 2x (0.5 - 2.5 mm²) (solid) |
| 1x (0.5 - 2.5 mm²), 2x (0.5 - 1.5 mm²) (stranded) | |
| Connectable AWG Wire Sizes | 2x (20 - 14) (solid and stranded) |
| Safety Functions | Guard Door Monitoring, Autostart, Monitored Start |
What is the main function of this Siemens safety relay?
The Siemens 3TK2825-1BB40 is a SIRIUS safety relay designed for emergency stop and protective door monitoring applications. It helps ensure the safety of personnel and equipment in industrial settings.
What are the input and output configurations of this safety relay?
The 3TK2825-1BB40 safety relay has 1 or 2 channel sensor inputs and features 3 normally open (NO) instant relay enabling circuits, 2 normally closed (NC) monitoring contacts, and no delayed relay enabling circuits.
What is the operating voltage of this safety relay?
The Siemens 3TK2825-1BB40 safety relay operates at a DC voltage of 24V.
What are the safety performance levels of this relay?
The 3TK2825-1BB40 safety relay has a Safety Integrity Level (SIL) of 3 according to IEC 61508 and a Performance Level (PL) of 'e' according to EN ISO 13849-1.
What is the operating temperature range for this safety relay?
The Siemens 3TK2825-1BB40 safety relay can operate in a temperature range of -25°C to +60°C.
What type of terminal connections does this safety relay have?
The 3TK2825-1BB40 safety relay features screw terminal connections for easy installation and secure connections.
What is the width of this safety relay?
The Siemens 3TK2825-1BB40 safety relay has a width of 45.0mm.
What are the protection classes of this safety relay?
The 3TK2825-1BB40 safety relay has an IP20 protection class for both the housing and the terminal connections.
- Emergency stop monitoring
- Safety door monitoring
- Safety mat monitoring
- Non-contact safety switch monitoring
- Position switch monitoring
- Safety-oriented relay circuits
- Safety sensor monitoring for potential-free sensors
- Integration in safety systems with up to SIL3 (IEC 61508) and PL e (EN ISO 13849-1) requirements
