3TK2822-1CB30
Siemens 3TK2822-1CB30 available at EU Automation. Get in touch today for a quick price.
Based on over 4900 reviews
Full 12-month warranty
Available for dispatch immediately
We deliver worldwide
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
All orders are subject to product availability. See our T&Cs.
Ask our team
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
The Siemens 3TK2822-1CB30 is a high-quality safety relay designed to ensure the utmost safety in your industrial automation processes. This safety relay operates with a control supply voltage of 24V AC/DC, making it a versatile choice for various applications. It features screw terminals for secure and reliable connections, ensuring a steady performance even in demanding conditions.
The 3TK2822-1CB30 is designed for mounting in any position, providing flexibility in installation. It has a compact width of 22.5mm, making it a space-saving solution for your safety automation needs. This safety relay is equipped with two normally open (NO) safety-related instantaneous contacts, making it suitable for protective door monitoring and pressure-sensitive mat monitoring.
With a robust design and proven reliability, the Siemens 3TK2822-1CB30 safety relay is an excellent choice for enhancing the safety and efficiency of your industrial automation systems.
The 3TK2822-1CB30 is designed for mounting in any position, providing flexibility in installation. It has a compact width of 22.5mm, making it a space-saving solution for your safety automation needs. This safety relay is equipped with two normally open (NO) safety-related instantaneous contacts, making it suitable for protective door monitoring and pressure-sensitive mat monitoring.
With a robust design and proven reliability, the Siemens 3TK2822-1CB30 safety relay is an excellent choice for enhancing the safety and efficiency of your industrial automation systems.
| Specification | Description |
|---|---|
| Part Number | 3TK2822-1CB30 |
| Alternative Part Number | 3TK28221CB30 |
| Manufacturer | Siemens |
| Category | Safety Automation |
| Description | This is a Siemens Safety Relay with relay enabling circuits (EC) operating at 24 V AC/DC. It has a compact size of 22.5 mm. |
| Short Description | Safety Relay with relay enabling circuits (EC) 24 V AC/DC, 22.5 mm |
| Country of Origin | Not specified |
| Commodity Code | 853649 |
| Mounting Type | Screw and snap-on mounting |
| Width | 22.5 mm |
| Height | 120 mm |
| Depth | 120 mm |
| Type of Electrical Connection | Screw-type terminals |
| Control Supply Voltage | 24 V AC/DC |
| Safety Integrity Level (SIL) | 3 |
| Performance Level (PL) | e |
| Category | 4 |
| Hardware Fault Tolerance | 1 |
| Safety Device Type | Type A |
| Stop Category | 0 |
| Ambient Temperature During Operation | -25 ... +60 °C |
| Ambient Temperature During Storage | -40 ... +80 °C |
| Protection Class IP of the Enclosure | IP40 |
| Protection Class IP of the Terminal | IP20 |
| Insulation Voltage Rated Value | 300 V |
| Vibration Resistance | 5 ... 500 Hz: 0,075 mm |
| Shock Resistance | 8g / 10 ms |
| Surge Voltage Resistance Rated Value | 4,000 V |
| EMC Emitted Interference | EN 60947-5-1 |
| Installation Environment Regarding EMC | Suitable for Class A environments only |
| Number of Sensor Inputs | 1 (2-channel) |
| Number of Outputs as Contact-Affected Switching Element | 2 (as NO contact) |
| Product Function | Protective door monitoring, automatic start, pressure-sensitive mat monitoring, monitoring of floating sensors, safety cut-out switch, position switch monitoring, safety-related circuits |
| Certificates/Approvals | BG, SUVA, UL, CSA, EN 60204-1, EN ISO 12100, EN 954-1, IEC 61508 |
| TÜV Certificate | Yes |
| UL Approval | Yes |
| BG BIA Certificate | Yes |
What is the category of this Siemens part?
The Siemens 3TK2822-1CB30 falls under the Safety Automation category.
What is the description of this part?
The Siemens 3TK2822-1CB30 is a Safety Relay with relay enabling circuits (EC) operating at 24 V AC/DC, and it has a 22.5 mm Screw terminal.
What is the short description of this part?
The short description of the Siemens 3TK2822-1CB30 is a Safety Relay with relay enabling circuits (EC) 24 V AC/DC, 22.5 mm.
What is the Commodity Code of this part?
The Commodity Code of the Siemens 3TK2822-1CB30 is 853649.
What are the common uses of this part?
The Siemens 3TK2822-1CB30 is commonly used in industrial automation systems for safety-related applications. It is designed to monitor and control safety functions in machines and industrial equipment.
What are the technical specifications of this part?
The Siemens 3TK2822-1CB30 operates at 24 V AC/DC, has a screw terminal, and is designed for safety-related applications. It has a width of 22.5 mm and is suitable for Class A environments only.
What is the country of origin of this part?
The country of origin for the Siemens 3TK2822-1CB30 is not specified.
What is the operating frequency of this part?
The Siemens 3TK2822-1CB30 has a maximum operating frequency of 1,000 1/h.
What is the installation environment regarding EMC for this part?
The Siemens 3TK2822-1CB30 is suitable for Class A environments only. It can cause undesired radio-frequency interference in residential environments.
What is the Safety Integrity Level (SIL) of this part?
The Siemens 3TK2822-1CB30 has a Safety Integrity Level (SIL) of 3 according to IEC 61508.
- Used in industrial automation systems for safety-related circuits
- Ideal for protective door monitoring in machinery and equipment
- Suitable for monitoring of floating sensors in various applications
- Commonly used in position switch monitoring in automated systems
- Utilized in safety switch applications for enhanced operational safety
- Perfect for applications requiring dual-channel monitored start
- Used in systems requiring Safety Integrity Level (SIL) 3 and Performance Level (PL) e
- Ideal for applications requiring hardware fault tolerance according to IEC 61508
- Suitable for use in Class A environments due to its EMC emitted interference
- Used in systems requiring stop category according to DIN EN
