METSECT5MC040
Schneider METSECT5MC040 available at EU Automation. Get in touch today for a quick price.
Based on over 4900 reviews
Full 12-month warranty
Available for dispatch immediately
We deliver worldwide
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
All orders are subject to product availability. See our T&Cs.
Ask our team
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
Schneider METSECT5MC040 is a PowerLogic tropicalised current transformer designed for accurate current measurement in electrical distribution and monitoring applications. Rated at 400/5 A with a 5 A secondary output, it supports Class 0.5 accuracy at 8 VA and Class 1 accuracy at 10 VA, making it suitable for metering and instrumentation tasks where dependable current sensing is required.
This current transformer is built for use with busbars and cables, with mounting options including DIN rail, mounting plate, busbar installation, clip-on fitting, insulated locking screw or screw fixing. It accommodates cable diameters up to 32 mm and bar openings of 25.5 x 25.5 mm, 40.5 x 10.5 mm and 32.5 x 20.5 mm. The unit has a rated operational voltage below 720 V AC at 50/60 Hz, 3 kV rated insulation and impulse withstand voltage, and a conventional free air thermal current rating of 24 kA.
With an IP20 protection rating, Class B electrical insulation and an operating temperature range from -25 to 60 °C, the METSECT5MC040 is suited to panel-based industrial and commercial electrical systems. Its compact frame, 400 g approximate weight and compliance with IEC 61869-2 and VDE 0414 standards make it a practical choice for integration into low-voltage power monitoring assemblies.
This current transformer is built for use with busbars and cables, with mounting options including DIN rail, mounting plate, busbar installation, clip-on fitting, insulated locking screw or screw fixing. It accommodates cable diameters up to 32 mm and bar openings of 25.5 x 25.5 mm, 40.5 x 10.5 mm and 32.5 x 20.5 mm. The unit has a rated operational voltage below 720 V AC at 50/60 Hz, 3 kV rated insulation and impulse withstand voltage, and a conventional free air thermal current rating of 24 kA.
With an IP20 protection rating, Class B electrical insulation and an operating temperature range from -25 to 60 °C, the METSECT5MC040 is suited to panel-based industrial and commercial electrical systems. Its compact frame, 400 g approximate weight and compliance with IEC 61869-2 and VDE 0414 standards make it a practical choice for integration into low-voltage power monitoring assemblies.
| Specification | Description |
|---|---|
| Manufacturer | Schneider Electric |
| Part Number | METSECT5MC040 |
| Product Range | PowerLogic |
| Product Type | Current transformer |
| Product Name | CT |
| Current Transformer Type | Tropicalised current transformer for busbar and cable applications |
| Rated Current | 400 A |
| Secondary Current | 5 A |
| Current Transformer Ratio | 400/5 |
| Accuracy Class | Class 0.5 at 8 VA; Class 1 at 10 VA |
| Rated Operational Voltage | < 720 V AC, 50/60 Hz |
| Rated Insulation Voltage | 3 kV |
| Rated Impulse Withstand Voltage | 3 kV |
| Conventional Free Air Thermal Current | 24 kA |
| Dynamic Withstand Current | 2.5 Ith |
| Maximum Safety Factor | 5 |
| Mounting Modes | Insulated locking screw, clip-on, or screw mounting |
| Mounting Supports | Busbar, DIN rail, or mounting plate |
| Outside Width | 70 mm |
| Inner Width | 41 mm |
| Outside Height | 95 mm |
| Inner Height | 41 mm |
| Frame Depth | 45 mm |
| Total Depth | 65 mm |
| Diameter | 32 mm |
| Cable Outer Diameter | 32 mm |
| Busbar Openings | 25.5 x 25.5 mm; 40.5 x 10.5 mm; 32.5 x 20.5 mm |
| Electrical Insulation Class | Class B |
| Sealing | Without sealing |
| Degree of Protection | IP20 |
| Operating Temperature | -25 to 60 °C |
| Relative Humidity | 0 to 95% |
| Standards | VDE 0414; IEC 61869-2 |
| Product Certifications | CE; EAC |
| Net Weight | 0.404 kg |
| Package Quantity | 1 unit |
| Package Dimensions | 9.0 cm x 7.3 cm x 12.0 cm |
| Package Weight | 400 g |
| Sustainability Compliance | EU RoHS compliant |
| WEEE Classification | Must be collected separately in EU markets and not placed in general waste |
What type of component is this?
It is a tropicalised current transformer designed for measuring high primary current and providing a 5 A secondary current for metering or monitoring equipment.
What current ratio does it provide?
The current transformer ratio is 400/5, meaning it is intended for a 400 A primary current with a 5 A secondary output.
What accuracy classes are specified?
It is rated as Class 0.5 at 8 VA and Class 1 at 10 VA, making it suitable for applications where defined metering accuracy is required.
What mounting options are available?
The unit can be mounted using an insulated locking screw, clip-on fitting or screws. It is suitable for installation on a busbar, DIN rail or mounting plate.
What conductor or busbar sizes can it accommodate?
It is designed for busbar openings of 25.5 x 25.5 mm, 40.5 x 10.5 mm and 32.5 x 20.5 mm. It can also accommodate a cable outer diameter of up to 32 mm.
What is the rated operational voltage?
The rated operational voltage is less than 720 V AC at 50/60 Hz.
What is the rated insulation voltage?
The rated insulation voltage is 3 kV, with a rated impulse withstand voltage of 3 kV.
What environmental conditions is it rated for?
It is rated for operation in ambient temperatures from -25 °C to 60 °C and relative humidity from 0% to 95%.
What ingress protection rating does it have?
The device has an IP20 degree of protection, which means it is protected against solid objects greater than 12.5 mm but is not rated for water ingress.
What standards and certifications are listed for this current transformer?
The listed standards include VDE 0414 and IEC 61869-2. The product certifications include CE and EAC.
What are the approximate dimensions?
The outside dimensions are approximately 70 mm wide by 95 mm high. The frame depth is 45 mm and the total depth is 65 mm.
What does tropicalised mean in this context?
In this context, tropicalised indicates that the current transformer is intended to better suit humid or demanding electrical enclosure environments within its stated operating limits.
What is the maximum safety factor?
The maximum safety factor is 5.
What is the conventional free air thermal current rating?
The conventional free air thermal current rating is 24 kA.
How much does the unit weigh?
The net weight is approximately 0.404 kg.
- Electrical current measurement in low-voltage power distribution panels
- Monitoring 400 A circuits using a 5 A secondary metering input
- Integration with PowerLogic metering and energy monitoring systems
- Current sensing for busbar-mounted electrical assemblies
- Retrofitting measurement capability into existing switchboards
- Use with ammeters, multifunction meters and power monitoring equipment
- Load monitoring in commercial and industrial electrical installations
- Energy usage analysis across machinery, plant and building services
- Current transformer installation on DIN rail, mounting plate or busbar arrangements
- Applications requiring a tropicalised current transformer for humid operating environments
