GB2DB08
Schneider GB2DB08 available at EU Automation. Get in touch today for a quick price.
Based on over 4900 reviews
Full 12-month warranty
Available for dispatch immediately
We deliver worldwide
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
All orders are subject to product availability. See our T&Cs.
Ask our team
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
The Schneider GB2DB08 is a high-quality thermal circuit breaker designed for reliable protection and control in electrical systems. This 2-pole circuit breaker is part of the TeSys GB2 range and is suitable for both AC and DC networks. It features a rated current of 3A and a breaking capacity of 3kA at 415V, making it ideal for various industrial applications. The GB2DB08 is equipped with thermal-magnetic trip technology, ensuring effective response to overloads and short circuits. It is designed for easy installation on DIN rails, with a compact form factor that saves space in control panels. The circuit breaker is compliant with EN/IEC 60947-2 standards, offering robust performance and safety. With an IP20 degree of protection, it is suitable for use in environments with ambient temperatures ranging from -20°C to 60°C. The Schneider GB2DB08 is a dependable choice for safeguarding electrical circuits, ensuring operational efficiency and safety.
| Specification | Description |
|---|---|
| Part Number | GB2DB08 |
| Manufacturer | Schneider Electric |
| Product Name | TeSys GB2 Thermal Magnetic Circuit Breaker |
| Poles Description | 2 Pole |
| Rated Current | 3 A |
| Rated Operational Voltage | 415 V AC 50/60 Hz, 48 V DC |
| Breaking Capacity | 3 kA at 230/240 V AC, 3 kA at 400/415 V AC, 1.5 kA at 24 V DC, 1 kA at 48 V DC |
| Trip Unit Technology | Thermal-magnetic |
| Magnetic Tripping Current | 40 A |
| Mounting Mode | By clips |
| Mounting Support | DIN Rail, Plate |
| Mounting Position | Vertical, Horizontal |
| Control Type | Toggle |
| Power Dissipation per Pole | 2 W |
| Mechanical Durability | 8000 cycles |
| Electrical Durability | 8000 cycles |
| Connections - Terminals | Connector for 1 cable(s) 0.75…6 mm² solid without cable end, Connector for 2 cable(s) 0.75…4 mm² solid without cable end, Connector for 1 cable(s) 0.75…4 mm² flexible with cable end, Connector for 2 cable(s) 0.75…2.5 mm² flexible with cable end |
| Tightening Torque | 1.2 N.m on connector |
| Mechanical Robustness | Shocks: 22 Gn for 20 ms, Vibrations: 5 Gn, 5...110 Hz |
| Dimensions (H x W x D) | 74 mm x 30 mm x 70 mm |
| Net Weight | 0.115 kg |
| Standards | EN/IEC 60947-1, EN/IEC 60947-2 |
| IP Degree of Protection | IP20 |
| Ambient Air Temperature | Operation: -20…60 °C, Storage: -40…80 °C |
| Fire Resistance | 960 °C |
| Operating Altitude | 3000 m |
| Sustainable Offer Status | Green Premium product, REACh free of SVHC, EU RoHS Compliant, Mercury free |
| Environmental Compliance | WEEE compliant, No need for specific recycling operations |
The Schneider Electric TeSys GB2DB08 is a robust thermal magnetic circuit breaker designed for reliable control applications. It features a 2-pole configuration with a rated current of 3 A, suitable for both AC and DC networks. The breaker is engineered to handle a breaking capacity of up to 3 kA at 415 V AC, ensuring effective protection in various electrical environments. Its compact design allows for easy installation on DIN rails or plates, and it supports both vertical and horizontal mounting positions. With a focus on sustainability, this product is compliant with major environmental standards, making it an ideal choice for eco-conscious applications.
What type of circuit breaker is this?
This is a Schneider Electric Thermal Circuit Breaker, specifically the TeSys GB2 series, designed for control applications.
What is the current rating of this circuit breaker?
The circuit breaker has a current rating of 3A.
What is the voltage rating for this circuit breaker?
The voltage rating for this circuit breaker is 277V AC.
How is this circuit breaker mounted?
This circuit breaker is designed for DIN rail mounting.
What is the breaking capacity of this circuit breaker?
The breaking capacity is 3kA at 230/240 V AC.
What are the dimensions of this circuit breaker?
The dimensions are 74mm in height, 30mm in width, and 70mm in depth.
What is the IP rating of this circuit breaker?
The circuit breaker has an IP20 degree of protection.
What is the operating temperature range for this circuit breaker?
The operating temperature range is from -20°C to 60°C.
Is this circuit breaker compliant with RoHS regulations?
Yes, this circuit breaker is compliant with the EU RoHS Directive.
What is the mechanical durability of this circuit breaker?
The mechanical durability is rated at 8000 cycles.
This content has been produced using multiple sources. EU Automation takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
