DF2CN04
Schneider DF2CN04 available at EU Automation. Get in touch today for a quick price.
Based on over 4900 reviews
Full 12-month warranty
Available for dispatch immediately
We deliver worldwide
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
All orders are subject to product availability. See our T&Cs.
Ask our team
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
Schneider DF2CN04 is a cylindrical cartridge fuse from the TeSys GS range, designed for dependable circuit protection in industrial control and panel applications. Rated at 4 A and 500 V AC, it uses a 10 x 38 mm format with a gG operating characteristic, making it well suited to providing general-purpose protection for cables and equipment against overload and short-circuit conditions.
This NFC fuse is supplied without striker indication and is provided as a set of 10, offering a practical choice for maintenance stock and panel build requirements. Compact in size and intended for use within compatible fuse-disconnector assemblies, the DF2CN04 is a straightforward solution for applications where consistent protection, recognised dimensions and reliable performance are essential.
This NFC fuse is supplied without striker indication and is provided as a set of 10, offering a practical choice for maintenance stock and panel build requirements. Compact in size and intended for use within compatible fuse-disconnector assemblies, the DF2CN04 is a straightforward solution for applications where consistent protection, recognised dimensions and reliable performance are essential.
| Specification | Description |
|---|---|
| Part number | DF2CN04 |
| Manufacturer | Schneider |
| Product type | Cylindrical cartridge fuse |
| Product range | TeSys fuse-disconnector |
| Device short name | DF2 |
| Fuse standard/type | NFC |
| Fuse characteristic | gG / GG general-purpose protection |
| Rated current | 4 A |
| Rated operational voltage | 500 V AC |
| Fuse size | 10 x 38 mm |
| Striker | Without striker |
| Quantity per set | Set of 10 parts |
| Construction | Cylindrical fuse format for compact panel integration |
| Typical use | Circuit protection in TeSys fuse-disconnector assemblies |
| Country of origin | France |
| Net weight | 0.01 kg |
What type of fuse is this?
This is a cylindrical cartridge fuse designed for general-purpose circuit protection. It uses a gG fuse characteristic, making it suitable for protecting cables and general electrical equipment against overloads and short circuits.
What are the main electrical ratings?
The fuse is rated at 4 A with a rated operational voltage of 500 V AC. For the correct result in service, it should be matched to equipment designed for the same fuse size and rating.
What size is the fuse?
It is a 10 x 38 mm cylindrical fuse. This size is commonly used in compact industrial fuse holders and fuse-disconnector assemblies.
What does the gG fuse characteristic mean?
A gG characteristic indicates full-range general protection. In practical terms, it is intended to provide protection against both overload conditions and short-circuit faults in general electrical circuits.
Is this fuse supplied with a striker pin?
No. This version is supplied without a striker. If your application requires fuse indication or mechanical tripping through a striker mechanism, the specification should be checked carefully before selection.
How many fuses are included?
This item is supplied as a set of 10 fuses, which can be useful for routine stockholding or planned replacement requirements.
Where is this fuse commonly used?
It is typically used in industrial electrical panels and fuse-disconnector applications where a 10 x 38 mm, 4 A, 500 V AC cylindrical fuse is required. DF2CN04 is associated with the TeSys GS fuse-disconnector range.
How can I check whether it is suitable for my equipment?
You should confirm the fuse size, current rating, voltage rating, fuse characteristic and striker requirement against the existing installation or the equipment documentation. The key checks for this item are 10 x 38 mm size, 4 A rating, 500 V AC and gG characteristic.
Can this be used as a like-for-like replacement?
It can be used as a like-for-like replacement when the original fuse has the same physical size, electrical rating and operating characteristic. Matching only the current rating is not enough; the voltage rating, fuse class and construction should also be the same.
Is this intended for panel-based industrial applications?
Yes. This fuse is intended for use in industrial control and distribution assemblies that accept cylindrical cartridge fuses of this format. Its compact 10 x 38 mm body makes it suitable for installations where space is limited.
- Protection of low-current industrial control circuits within panels and enclosures
- General-purpose overcurrent protection for 500 V AC circuits using 10 x 38 mm cylindrical fuse holders
- Use in TeSys GS fuse-disconnector assemblies for isolating and protecting branch circuits
- Protection of auxiliary power circuits feeding contactors, relays and interface components
- Safeguarding panel-mounted signalling, indication and control devices against fault currents
- Integration into OEM machinery panels where compact cylindrical fuse protection is required
- Protection of cable runs and downstream devices in light industrial distribution arrangements
- Use in switchboards and control cabinets for neatly organised, replaceable fuse protection
- Suitable for electrical assemblies that require a 4 A gG fuse for general circuit protection
- Commonly fitted in manufacturing equipment, process lines and automation cabinets with modest current demands
This content has been produced using multiple sources. EU Automation takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
