KL2022
Beckhoff KL2022 available at EU Automation. Get in touch today for a quick price.
Based on over 4900 reviews
Full 12-month warranty
Available for dispatch immediately
We deliver worldwide
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
All orders are subject to product availability. See our T&Cs.
Ask our team
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
| Specification | Description |
|---|---|
| Part Number | KL2022 |
| Alternative Part Number | KL2022 |
| Manufacturer | Beckhoff |
| Connection Technology | 4-wire |
| Number of Outputs | 2 |
| Rated Load Voltage | 24 V DC (-15 %/+20 %) |
| Load Type | Ohmic, inductive, lamp load |
| Max. Output Current | 2.0 A (short-circuit-proof) per channel |
| Short Circuit Current | < 70 A |
| Breaking Energy | < 1.7 J/channel |
| Reverse Voltage Protection | Yes |
| Electrical Isolation | 500 V rms (K-bus/field potential) |
| Current Consumption Power Contacts | Typical 20 mA |
| Current Consumption K-bus | Typical 5 mA |
| Bit Width in the Process Image | 2 outputs |
| Configuration | No address or configuration setting |
| Weight | Approximately 55 g |
| Operating/Storage Temperature | 0…+55 °C/-25…+85 °C |
| Relative Humidity | 95 %, no condensation |
| Vibration/Shock Resistance | Conforms to EN 60068-2-6/EN 60068-2-27/29 |
| EMC Immunity/Emission | Conforms to EN 61000-6-2/EN 61000-6-4 |
| Protection Class/Installation Position | IP 20/variable |
| Pluggable Wiring | For all KSxxxx Bus Terminals |
The Beckhoff KL2022 is a 2-channel digital output terminal that connects binary control signals from the automation unit to the actuators at the process level with electrical isolation. It handles different load currents and its outputs are protected against short-circuit. The terminal contains two channels that indicate their signal state by means of light-emitting diodes. It operates with a 4-wire connection technology and has a rated load voltage of 24 V DC. The KL2022 is designed to handle ohmic, inductive, and lamp loads. It offers reverse voltage protection and conforms to various EN standards for vibration/shock resistance and EMC immunity/emission.
What is the function of the Beckhoff KL2022 part?
The Beckhoff KL2022 is a digital output terminal that connects the binary control signals from the automation unit to the actuators at the process level with electrical isolation. It handles different load currents, and its outputs are protected against short-circuit. The terminal contains two channels that indicate their signal state by means of light emitting diodes.
What is the connection technology of the Beckhoff KL2022?
The Beckhoff KL2022 uses a 4-wire connection technology.
How many outputs does the Beckhoff KL2022 have?
The Beckhoff KL2022 has two outputs.
What is the rated load voltage of the Beckhoff KL2022?
The rated load voltage of the Beckhoff KL2022 is 24 V DC (-15 %/+20 %).
What types of load can the Beckhoff KL2022 handle?
The Beckhoff KL2022 can handle ohmic, inductive, and lamp load types.
What is the maximum output current of the Beckhoff KL2022?
The maximum output current of the Beckhoff KL2022 is 2.0 A (short-circuit-proof) per channel.
Does the Beckhoff KL2022 have reverse voltage protection?
No, the Beckhoff KL2022 does not have reverse voltage protection.
What is the operating and storage temperature of the Beckhoff KL2022?
The operating temperature of the Beckhoff KL2022 is 0 to +55 °C and the storage temperature is -25 to +85 °C.
What is the protection class of the Beckhoff KL2022?
The protection class of the Beckhoff KL2022 is IP20.
- Control of industrial automation processes
- Connection of binary control signals from automation units to actuators
- Use in systems requiring electrical isolation at the process level
- Suitable for different load currents, including ohmic, inductive, and lamp loads
- Ideal for systems requiring short-circuit protection
- Use in systems where signal state indication is necessary
- Applicable in 4-wire connection technology systems
- Suitable for systems requiring a rated load voltage of 24 V DC
- Use in environments requiring vibration and shock resistance
- Ideal for systems requiring EMC immunity and emission conformity
- Suitable for use in environments with a temperature range of 0 to +55 °C
- Applicable in systems requiring a protection class of IP 20.
This content has been produced using multiple sources. EU Automation takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
