XB4BG21
Schneider XB4BG21 available at EU Automation. Get in touch today for a quick price.
Based on over 4900 reviews
Full 12-month warranty
Available for dispatch immediately
We deliver worldwide
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
All orders are subject to product availability. See our T&Cs.
Ask our team
What happens next?
1. Email confirmation
You will get an email confirming that we have received your enquiry.
2. Dedicated Account Manager
One of our team will be in touch to confirm your part(s) specification and condition.
3. Your quote
You will receive a comprehensive quote tailored to your specific needs.
The Schneider XB4BG21 is a robust and reliable selector switch, designed for industrial applications. This high-quality component is part of the Harmony XB4 range, renowned for its durability and performance. The switch features a chromium-plated metal bezel and a Zamak fixing collar, ensuring it can withstand demanding environments.
With a mounting diameter of 22mm, the XB4BG21 is compact and easy to install. It operates in a 'stay put' mode, meaning it maintains its position until manually changed, providing consistent and reliable control. The operator profile is a key switch, offering enhanced security and control.
The switch has two positions at 90°, and its contacts type and composition is 1 NO (Normally Open). It also features slow-break contact operation, which helps to minimise electrical wear and extend the lifespan of the switch.
The XB4BG21 is rated for 10A at 600V, making it suitable for a wide range of industrial applications. It has a mechanical durability of 1,000,000 cycles, demonstrating its long-lasting performance.
Please note, this product is designed for professional installation and use. Always ensure that installation and operation are carried out by qualified personnel.
With a mounting diameter of 22mm, the XB4BG21 is compact and easy to install. It operates in a 'stay put' mode, meaning it maintains its position until manually changed, providing consistent and reliable control. The operator profile is a key switch, offering enhanced security and control.
The switch has two positions at 90°, and its contacts type and composition is 1 NO (Normally Open). It also features slow-break contact operation, which helps to minimise electrical wear and extend the lifespan of the switch.
The XB4BG21 is rated for 10A at 600V, making it suitable for a wide range of industrial applications. It has a mechanical durability of 1,000,000 cycles, demonstrating its long-lasting performance.
Please note, this product is designed for professional installation and use. Always ensure that installation and operation are carried out by qualified personnel.
| Specification | Description |
|---|---|
| Part Number | XB4BG21 |
| Manufacturer | Schneider |
| Description | This is a Telemecanique Selector Switch, designed for robust and reliable operation. |
| Current Rating | 10 A |
| Voltage Rating | 600 V |
| Lifecycle | Capable of 1000000 cycles |
| Selector Type | Stay put |
| Positions | 2 positions at 90° |
| Contact Composition | 1 Normally Open (NO) |
| Material | Bezel made of Chromium plated metal, Fixing collar made of Zamak |
| Mounting Diameter | 22 mm |
| Product Weight | 0.117 kg |
| Resistance | Resistant to high pressure washer up to 7000000 Pa at 55 °C |
| Keylock Type | Ronis 455 |
| Key Withdrawal Position | Left-hand |
| Mechanical Durability | 1000000 cycles |
| Contact Material | Silver alloy (Ag/Ni) |
| Short-Circuit Protection | 10 A cartridge fuse type gG |
| Rated Insulation Voltage | 600 V (degree of pollution: 3) |
| Rated Operational Current | Varies based on voltage and AC/DC current |
| Electrical Durability | 1000000 cycles |
| Commodity Code | 853620 |
| Country of Origin | Not specified |
What type of switch is this?
This is a key switch selector, part of the Harmony XB4 series, designed for industrial control panels.
What are the dimensions of the switch?
The switch has a mounting diameter of 22 mm, a height of 47 mm, a width of 30 mm, and a depth of 86 mm.
Can this switch be used in outdoor applications?
Yes, the switch has an IP66 rating, making it suitable for outdoor use as it is protected against dust and powerful water jets.
What is the electrical durability of this switch?
The switch has an electrical durability of 1,000,000 cycles for AC-15 usage under specified conditions.
What materials are used in the construction of this switch?
The bezel is made from chromium plated metal and the fixing collar is constructed from Zamak.
Is this switch compliant with environmental regulations?
Yes, it is a Green Premium product, which means it complies with the latest environmental regulations and is free from harmful substances.
What type of contacts does the switch have?
The switch is equipped with one normally open (NO) contact.
What is the rated operational current of the switch?
The switch has a rated operational current of 10 A for thermal current in free air and various ratings for operational current depending on the voltage and AC or DC operation.
What is the torque value for the switch?
The recommended torque value for changing the electrical state is 0.14 N.m.
How is the switch mounted?
The switch is designed to be panel mounted with a clamping thickness of 1 to 6 mm.
- Control of machinery and industrial equipment
- Use in control panels for selecting different modes of operation
- Integration in safety systems for emergency stop functions
- Utilization in automation systems for manual control
- Application in manufacturing processes for equipment selection
- Use in electrical circuits as a switch to control power distribution
- Implementation in HVAC systems for mode selection
- Use in marine applications due to its high resistance to pressure and temperature
- Integration in control systems for lighting and other electrical installations
- Application in conveyor systems for manual control of conveyor belts.
This content has been produced using multiple sources. EU Automation takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
