KJ1501X1-BC3 Emerson
Based on over 4900 reviews
Adding another part to your enquiry?
After submitting this form, you can add additional part numbers and quantities using the quote builder on the next page. A member of our team will then be in touch to discuss your quote.
Key specifications
Manufacturer
Emerson
HS code
8504.40
Ship to
Canada
Availability
13 remaining
Express delivery to Canada
Full 12-month warranty
Secure payment process
What happens next?
From enquiry to delivery, we keep it simple.
Submit your enquiry
Tell us what you need using the form above and we'll manage your procurement needs with speed and care.
Confirmation and sourcing
An account manager will contact you within a few hours and use our unique parts database to find your components at a competitive price.
Receive your quote
Your account manager will provide a tailored quote outlining availability and delivery dates.
Place your order
Your order ships quickly from one of our global logistics hubs, with updates provided every step of the way.
The Emerson KJ1501X1-BC3 is a robust system dual DC power supply component designed to deliver reliable and efficient power distribution within industrial automation systems. Engineered to operate in a wide range of environmental conditions, this power supply unit is capable of withstanding ambient temperatures from -40 to 70 degrees Celsius, making it suitable for challenging industrial settings. With an input voltage range of 11.5 VDC to 28.8 VDC, the KJ1501X1-BC3 ensures flexible integration into various system configurations. It provides a total output power of 10.2 W at 70 degrees Celsius, combining outputs of 5 VDC and 3.3 VDC. The output rating is 12 VDC at 13 A max up to 60 degrees Celsius or 12 VDC at 10 A max up to 70 degrees Celsius with a 12 VDC input. For a 24 VDC input, the output is 12 VDC at 8 A max up to 60 degrees Celsius or 12 VDC at 6 A max up to 70 degrees Celsius. The unit is also designed to handle shock and vibration, with a shock resistance of 10 G ½-sinewave for 11 ms and vibration tolerance of 1 mm peak-to-peak from 5 Hz to 16 Hz, and 0.5 g from 16 Hz to 150 Hz. It is compliant with ISA-S71.04–1985 Airborne Contaminants Class G3, ensuring operation in environments with airborne particulates. This power supply is specifically tailored for installations that require adherence to stringent environmental and safety standards, including ATEX Zone 2 and Class I Division 2 Groups A, B, C, and D hazardous locations, with a temperature rating of T4. It is important to note that the unit must not be removed or inserted while system power is energized, and it contains no user-serviceable parts, eliminating the need for disassembly or calibration. The Emerson KJ1501X1-BC3 is a testament to Emerson's commitment to quality and reliability, providing a dependable power solution for industrial automation systems that demand precision and durability.
Typical applications
- Power supply for DeltaV automation systems in process industries
- Energy source for electronic modules in hazardous environments
- Dual DC power supply for control systems in oil and gas facilities
- Backup power solution for critical process control equipment
- Powering field communication interfaces in chemical plants
- Supplying power to sensors and actuaries in pharmaceutical manufacturing
- Energy provision for safety instrumented systems
- Electrical supply for distributed control systems in power generation plants
- Power source for environmental monitoring equipment in refineries
- Providing low voltage DC power in pulp and paper mills
